NOCK CORTEX CBP496 / CBP695 POULTRY SKINNING

Enquire Now

  • NOCK CORTEX CBP496 / CBP695 POULTRY SKINNINGAutomatic poultry skinning machine for chicken legs skinning, chicken thighs skinning, chicken drumsticks skinning and chicken breast skinning.
    • automatic skinning machine for whole chicken legs, chicken drumsticks, chicken thighs and chicken breast
    • chicken breast can also be skinned with an alternative pressure roller

    FEATURES AND APPLICATION RANGE

    cutting width: 430 mm /  600 mm
    cutting speed 24 m/min
    application
    • automatic skinning machine for whole chicken legs, chicken drumsticks, chicken thighs and chicken breast
    • chicken breast can also be skinned with an alternative pressure roller

    STANDARD EQUIPMENT

    • special chicken skinning blade
    • spring suspended blade holder
    • special transport roller for chicken skinning
    • spring suspended pressure roller, infinitely adjustable in height
    • special, star shaped pressure wheels to skin chicken legs (whole legs, thighs, drumsticks)
    • optional special pressure roller to skin chicken breast
    • dynamic stainless steel cleaning roller
    • NOCK Air-Jet compressed air cleaning system
    • infeed conveyor
    • discharge conveyor
    • NOCK POWER PLATES® for outstanding robustness and service friendliness
    • NOCK EASY-FLOW® safety cover for reliable product flow and better processing hygiene
    • lockable castors
    • stainless steel
    • stainless steel bearings

    OPTIONS

    • discharge conveyor for removed skin
    • plastic modular belts
    • NEW: Cleaning trolley for storage and cleaning of dismountable parts like: conveyors, belts, pressure roller and blade holder

    TECHNICAL DATA

    Cortex CBP 496 POULTRY Cortex CBP 695 POULTRY
    cutting width 430 mm 600 mm
    cutting speed 24 m/min 24 m/min
    maximum throughput height 90 mm 90 mm
    apply length on infeed conveyor 400 mm 400 mm
    infeed conveyor (1) 850 x 425 mm 1070 x 590 mm
    discharge conveyor (1) 850 x 425 mm 1070 x 590 mm
    discharge conveyor for removed skin (1) 650 x 425 mm 850 x 590 mm
    overall dimension W x H x D 800 x 1190 x 1860 mm 965 x 1190 x 2230 mm
    weight 240 kg 300 kg
    motor performance 0.75 kW 1.1 kW
    electrical connection 3 AC – 400 V – 50 Hz
    IEC 60309 16 A 6h
    other voltages upon request    		 3 AC – 400 V – 50 Hz
    IEC 60309 16 A 6h
    other voltages upon request
    compressed air connection 5  < p < 10 bar
    plug coupling DN 7.2 (G 1/4 external)    		 5 < p < 10 bar
    plug coupling DN 7.2 (G 1/4 external)
    compressed air consumption approx. 250 l/min (surrounding pressure) approx. 250 l/min (surrounding pressure)
    water consumption not required not required

    (1) external dimension of the conveyor frame
