NOCK CORTEX CB 496 GYROS – NOCK12-GYROS
NOCK CORTEX CB 496 GYROS
NOCK CORTEX CB 496 GYROS
Smaller cutting width to gently cut high quality slices of meat for Doner and Gyros meat skewers and stir-fry dishes. The CB 496 has the option to add an integrated return system or a discharge conveyor. This model can also be modular linked for multi cut lines.
FEATURES AND APPLICATION RANGE
| cutting width: | 430 mm |
| cutting speed: | 24 m/min |
| features: |
|
| application: | Suitable for veal, bull beef, pork, turkey breast, lamb |
STANDARD EQUIPMENT
- blade gap infinitely adjustable 0.5 – 8 mm
- blade holder spring suspended
- pressure roller spring suspended and continuously adjustable in height
- tooth roller with scraper comb
- infeed conveyor
- NOCK POWER PLATES® for special robustness and service friendliness
- conveyors can be taken out of the machine without any tools within seconds
- lockable castors
- stainless steel
- stainless steel bearings
OPTIONS
- INTEGRATED NOCK PRODUCT RETURN SYSTEM® (highly recommended!)
- discharge conveyor for the sliced meat (for feeding of huge bins, e.g. meat trolleys)
- discharge conveyor for remaining uncut meat (not together with INTEGRATED NOCK PRODUCT RETURN SYSTEM®)
- multi cut lines
- NEW: Cleaning trolley for storage and cleaning of dismountable parts like: conveyors, belts, pressure roller and blade holder
TECHNICAL DATA
| Cortex CB 496 GYROS | |
|---|---|
| cutting width | 430 mm |
| cutting speed | 24 mm/min |
| cutting direction | horizontally |
| max. throughput height | 90 mm |
| blade gap | 0.5 – 8 mm infinitely adjustable other thicknesses upon request |
| apply length on infeed conveyor | 400 mm (with Integrated Product Return System®) |
| infeed conveyor (1) | 850 x 425 mm |
| discharge conveyor for cut meat slices (1) | 850 x 425 mm |
| overall dimension W x H x D (with Integrated Product Return System®) | 910 x 1190 x 1210 mm |
| weight | 240 kg |
| motor performance | 0.75 kW |
| electrical connection | 3 AC – 400 V – 50 Hz IEC 60309 16 A 6h other voltages upon request |
| compressed air | not required |
|
